H8P/H10P 8,000 –10,000 lb./ 3,630–4,540 kg
|
Proven robust construction engineered to meet J706 standards
|
|
High efficiency 2 stage planetary gearbox giving optimum reliability
Integral, automatic, fail safe brake
|
|
Rugged, high torque motor unit of proven reliability
|
|
Spring engaged, manual freespooling, released for rapid rope payout, pneumatic
option also available, adjustable Freespool Damper
|
|
Heavy duty fabricated steel mounted on maintenance-free plain bearings
|
|
H8P
|
|
|
Maximum Oil Pressure
|
1,800 psi
|
|
Maximum Oil Flow
|
15gpm (57 l/min.)
|
|
Line Pull (Second Layer)
|
6,658 lbs. (3,020kg)
|
|
Line Pull (Third Layer)
|
5,710 lbs. (2,590kg)
|
|
Line Pull (Fourth Layer)
|
4,892 lbs. (2,260kg)
|
|
H10P
|
|
|
Maximum Oil Pressure
|
1,700 psi
|
|
Maximum Oil Flow
|
15gpm (57 l/min.)
|
|
Line Pull (Second Layer)
|
8,200 lbs. (3,720kg)
|
|
Line Pull (Third Layer)
|
6,970 lbs. (3,160kg)
|
|
Line Pull (Fourth Layer)
|
6,040 lbs. (2,740kg)
|
|
H8P
|
|
|
Rated Line Pull (Bottom Layer)
|
8,000 lb. (3,630 kg)
|
|
Line Speed, Bottom Layer, No Load
|
40'/min. (12.19m/min.)
|
|
Recommended Wire Rope Diameter
|
3/8" (10mm)
|
|
Short Drum Wire Rope Length
|
100' (30m)
|
|
Long Drum Wire Rope Length
|
130' (40m)
|
|
Drum Diameter
|
3.5" (89mm)
|
|
Weight (Excluding Wire Rope)
|
84 lbs. (38/40 kg)
|
|
H10P
|
|
|
Rated Line Pull (Bottom Layer)
|
10,000 lb. (4,540 kg)
|
|
Line Speed, Bottom Layer, No Load
|
30'/min. (9.14m/min.)
|
|
Recommended Wire Rope Diameter
|
7/16" (11mm)
|
|
Short Drum Wire Rope Length
|
75' (23m)
|
|
Long Drum Wire Rope Length
|
100' (30m)
|
|
Drum Diameter
|
3.5" (89mm)
|
|
Weight (Excluding Wire Rope)
|
84 lbs. (38 kg)
|
|
H8P Winch only (Short Drum)
|
5050A
|
|
H8P Winch only (Long Drum)
|
5060A
|
|
H10P Winch only (Short Drum)
|
5170A
|
|
H10P Winch only (Long Drum)
|
5178A
|
|
Roller Fairlead (Short Drum)
|
5600
|
|
Roller Fairlead (Long Drum)
|
5610A
|
|
Cable Tensioner(Short Drum)
|
5606
|
|
Cable Tensioner (Long Drum)
|
5607
|
|
Flat-Bed Mount Plate
|
5625
|
|
Pneumatic Freespool
|
5603
|
|
Pulley Block, 20,000 lb. (9,100kg)
|
7750A
|
|
